Astra Round
Astra surfaced mounted range of LED ceiling lights are a perfect fit for varied lighting applications. The die cast aluminium housing is ideal for better thermal management. High lumen output / different wattage options make this luminaire versatile for indoor lighting solutions.
Product Description
• Luminaire made of die-cast aluminium for better thermal management.
• Die-cast aluminium inner ring with reflector for uniform light distribution.
• High PF constant current LED driver.
• Cable entries for through-wiring of mains supply cable
• Available in 30° beam angle
• Suitable for operation on 240V, 50Hz single phase ac supply.
• Safety class II
• Ordering guide : KL-23683-CCT (Colour Temperature)
• Available CCT : 2700K, 3000K, 4000K, 6500K.
Product Benefits
• Excellent efficiency for high energy savings of up to 80% compared to CFL downlights.
• Replacement of existing CFL downlights with even better performance.
• Quick & simple installation.
• Sustainable LED technology offers durability and optimal light output with low power consumption.
Area of Application
Lobbies & Foyers, Retail Sector, Corridors, Corporate, Residential & Educational premises, Hospitality Industry, Commercial & Business Centers, etc.
Available Finish
Epoxy polyester powder coated Black & Rose Gold.
Product Description
• Luminaire made of die-cast aluminium for better thermal management.
• Die-cast aluminium inner ring with reflector for uniform light distribution.
• High PF constant current LED driver.
• Cable entries for through-wiring of mains supply cable
• Available in 30° beam angle
• Suitable for operation on 240V, 50Hz single phase ac supply.
• Safety class II
• Ordering guide : KL-23683-CCT (Colour Temperature)
• Available CCT : 2700K, 3000K, 4000K, 6500K.
Product Benefits
• Excellent efficiency for high energy savings of up to 80% compared to CFL downlights.
• Replacement of existing CFL downlights with even better performance.
• Quick & simple installation.
• Sustainable LED technology offers durability and optimal light output with low power consumption.
Area of Application
Lobbies & Foyers, Retail Sector, Corridors, Corporate, Residential & Educational premises, Hospitality Industry, Commercial & Business Centers, etc.
Available Finish
Epoxy polyester powder coated Black & Rose Gold.
| ID | Specification | IES | Photometry | Technical Datasheet | Technical Description |
|---|---|---|---|---|---|
| 23685 | CCT : 3000K, 4000K, 5700K, 2700K CRI : 90 Optics : 30° Accessories : No Accessories ProductFinishColour : Black&RoseGold Warranty : 3 Years Diffuser : Clear Polycarbonate | 23685-BA30°-WW.IES 23685-BA30°-CW.IES 23685-BA30°-NW.IES |
23685-BA30°-WW.PDF 23685-BA30°-CW.PDF 23685-BA30°-NW.PDF |
23685.pdf | 23685.txt |
| 23683 | CCT : 3000K, 4000K, 6500K, 2700K CRI : 90 Optics : 30° Accessories : No Accessories ProductFinishColour : Black&RoseGold, White&RoseGold Warranty : 3 Years Diffuser : Clear Polycarbonate | 23683-BA30°-WW.IES 23683-BA30°-CW.IES 23683-BA30°-NW.IES |
23683-BA30°-WW.PDF 23683-BA30°-CW.PDF 23683-BA30°-NW.PDF |
23683.pdf | 23683.txt |
| 23684 | CCT : 3000K, 4000K, 6500K, 2700K CRI : 90 Optics : 30° Accessories : No Accessories ProductFinishColour : Black&RoseGold Warranty : 3 Years Diffuser : Clear Polycarbonate | 23684-BA30°-WW.IES 23684-BA30°-CW.IES |
23684-BA30°-WW.PDF 23684-BA30°-CW.PDF |
23684.pdf | 23684.txt |
Configuration Options
