Stellar 15 - SV
The Stellar silicone co-extrusion flex is an advanced lighting solution designed for durability and performance. Offering exceptional UV resistance, chemical stability and abrasion resistance, this flexible luminaire is ideal for both indoor and outdoor applications. With an IP67 rating, it is fully protected against dust and water ingress, ensuring reliable use in demanding environments. The flexible design allows for easy horizontal bending, delivering a uniform light output along its entire length. Additionally the Stellar flex can be configured to the precise length needed with small cutting increments, allowing for seamless and flexible installation in various settings.
Product Description
• Ultra bright LED Silicone - Side View
• Anti-UV for outdoor use.
• Flexible horizontal bending diameter of >150mm for easy of installation.
• Available in 120° beam angle.
• Even light distribution & no dot spots.
• CRI ( Ra) : >90
• Constant voltage non integral power supply
• Low Voltage at 24Vdc assures safety.
Product Benefits
• Dot free and absolutely homogeneous light emission surface.
• Flexibility combined with high durability.
• High luminous flux
• High colour consistency
Areas of Application
• Signboard
• Logo
• Accent Lighting
• Hospitality Industry
• Commercial & Business Centers
Product Description
• Ultra bright LED Silicone - Side View
• Anti-UV for outdoor use.
• Flexible horizontal bending diameter of >150mm for easy of installation.
• Available in 120° beam angle.
• Even light distribution & no dot spots.
• CRI ( Ra) : >90
• Constant voltage non integral power supply
• Low Voltage at 24Vdc assures safety.
Product Benefits
• Dot free and absolutely homogeneous light emission surface.
• Flexibility combined with high durability.
• High luminous flux
• High colour consistency
Areas of Application
• Signboard
• Logo
• Accent Lighting
• Hospitality Industry
• Commercial & Business Centers
| ID | Specification | IES | Photometry | Technical Datasheet | Technical Description |
|---|---|---|---|---|---|
| 23397 | Dimension : 5000, 4000, 3000, 2000, 1000 Wattage : 10W/m, 15W/m, 14.5W/m CCT : 3000K, RGBW Pixel (W-3000K) CRI : 90 Accessories : Front Cable Entry+End cap, Side Cable Entry+End cap, Bottom Cable Entry+End cap, Front Cable Entry+Front Cable Entry, Side Cable Entry+Side Cable Entry, Bottom Cable Entry+Bottom Cable Entry Warranty : 2 Years LuminaireOption : DMX512, On/Off, Serial Peripheral Interface Mounting : No Accessories, 3 Nos Al. Clamp (20mm), 6 Nos Al. Clamp (20mm), 9 Nos Al. Clamp (20mm), 12 Nos Al. Clamp (20mm), 15 Nos Al. Clamp (20mm) | 23397.pdf |
Accessories you may need
- 68405 - Stellar 15 - Side bend - Aluminium Clamp
- 68406 - Stellar 15 - Side bend - SS Clamp
- 68407 - Stellar 15 - Side bend - SS Channel
- 68408 - Stellar 15 - Direct Entry Connector
- 68409 - Stellar15 - Side Entry Connector
- 68410 - Stellar 15 - Bottom Entry Connector
- 68411 - Stellar 15 - End Cap
Configuration Options
