Aarsh
At first glance, Aarsh looks like a beautiful miniature moon. Its unique shape and texture make it an eye-catching and attractive addition to any room. But Aarsh is more than just a decorative item. It has been engineered to be extremely versatile and can be used in many different ways.
Product Description
• Ring shaped body made of extruded aluminium (Grade 6063).
• High efficiency Translucent acrylic diffuser for glare free, uniform light distribution, additional Prismatic diffuser available on request for better glare control.
• Adjustable stainless steel suspension kit(1 or 2 metre) available on request.
• Colour rendering index (CRI) is >80
• Cable entries for through-wiring of mains supply cable
• Integral constant current power supply.
• Suitable for operation on 240V, 50Hz single phase ac supply.
• Ordering guide : KL-2850-CCT (Colour Temperature), Tunable (On Request)
• Available CCT: 3000K, 4000K (6000K On Request).
Product Benefits
• High luminous efficiency at reduced wattage.
• Environmental friendly.
• Visual comfort with Elegance, Functionality.
• Sturdy construction in order to maintain performance of the luminaire and to reduce maintenance costs.
Area of Application
Corporate Offices, Lobbies, Shopping Malls, Restaurants, Receptions, Commercial & Business Centers.
Available Finish
White / Black epoxy polyester powder coating.
Product Description
• Ring shaped body made of extruded aluminium (Grade 6063).
• High efficiency Translucent acrylic diffuser for glare free, uniform light distribution, additional Prismatic diffuser available on request for better glare control.
• Adjustable stainless steel suspension kit(1 or 2 metre) available on request.
• Colour rendering index (CRI) is >80
• Cable entries for through-wiring of mains supply cable
• Integral constant current power supply.
• Suitable for operation on 240V, 50Hz single phase ac supply.
• Ordering guide : KL-2850-CCT (Colour Temperature), Tunable (On Request)
• Available CCT: 3000K, 4000K (6000K On Request).
Product Benefits
• High luminous efficiency at reduced wattage.
• Environmental friendly.
• Visual comfort with Elegance, Functionality.
• Sturdy construction in order to maintain performance of the luminaire and to reduce maintenance costs.
Area of Application
Corporate Offices, Lobbies, Shopping Malls, Restaurants, Receptions, Commercial & Business Centers.
Available Finish
White / Black epoxy polyester powder coating.
| ID | Specification | IES | Photometry | Technical Datasheet | Technical Description |
|---|---|---|---|---|---|
| 22821 | CCT : 3000K, 4000K, 5700K, 2700K CRI : >80 Accessories : No Accessories, 1m Suspension Kit ProductFinishColour : RAL 9004 Black, Graphite Grey, RAL 7016 Anthracite Grey, RAL 9007 Grey Aluminium, RAL 9016 Traffic White Warranty : 5 Years LuminaireOption : Uplight Not Required, Uplight Mono Colour, Uplight RGBW, Not Applicable Mounting : Surface, Suspension Diffuser : Acrylic Prismatic, Acrylic Translucent Controls : Dali 2 | 22821.pdf | 22821.txt | ||
| 22850 | CCT : 3000K, 4000K, 5700K, 2700K CRI : >80 Accessories : No Accessories, 1m Suspension Kit ProductFinishColour : RAL 9004 Black, Graphite Grey, RAL 7016 Anthracite Grey, RAL 9007 Grey Aluminium, RAL 9016 Traffic White Warranty : 5 Years LuminaireOption : Uplight Not Required, Uplight Mono Colour, Uplight RGBW, Not Applicable Mounting : Surface, Suspension Diffuser : Acrylic Translucent, Acrylic Prismatic Controls : Switchable | 22850-BA--ww.IES |
22850-BA--ww.PDF |
22850.pdf | 22850.txt |
| 22842 | CCT : 3000K, 4000K, 5700K, 2700K CRI : >80 Accessories : No Accessories, 1m Suspension Kit ProductFinishColour : RAL 9004 Black, Graphite Grey, RAL 7016 Anthracite Grey, RAL 9007 Grey Aluminium, RAL 9016 Traffic White Warranty : 5 Years LuminaireOption : Uplight Not Required, Uplight Mono Colour, Uplight RGBW, Not Applicable Mounting : Surface, Suspension Diffuser : Acrylic Prismatic, Acrylic Translucent Controls : Dali 2 | 22842-BANA-NW.IES |
22842-BANA-NW.PDF |
22842.pdf | 22842.txt |
Configuration Options
